104: Declination 1, 2, 3...
A map and compass (and how to use them) often tops the list of backpacking essentials. The Brunton Basic Compass Clinics are the first in an ongoing series of bite sized lessons that will make compass and map use easy and accessible. Our goal is to address any negative stigmas or anxiety around using a compass and map that is often a roadblock for both new and experienced outdoor explorers. We hope to remove these barriers and help people navigate outdoors with confidence.
In the fourth instalment of the Brunton Basic Compass Clinics, we'll discuss declination and how to adjust your compass for it.
First of all what exactly is declination?
According to the US Geological Survey (USGS), the amount of deviation of a compass needle from true north is an angle called declination, or magnetic declination.
So what exactly does that mean?
- On the globe above we have true north, or the geographic north pole.
- We also have the magnetic north pole, this is not static and moves over time (geologically speaking).
- Then we have a location, we will use New York in this scenario.
- Using these three points, we can figure out the declination for New York by drawing a line from it directly to "True North" (the red line).
- Then we draw a line from New York to "Magnetic North" (the pink line).
- The angle of deviation (or the blue area) between the two arrows is the declination.
So how does this look on a compass face?
- True north is represented again by the red arrow.
- Magnetic North, by the pink arrow.
- The blue is the difference between the two, or the declination.
- New York is currently 13 degrees West Declination.
Declination Location Examples
As one moves across the country or globe, the declination changes. Below are three different locations, Mount Rainier in Seattle, Gannett Peak in the Wind River Range in Wyoming and Acadia National Park in Maine.
Practical Declination
What is your declination and how to set it?
The declination for an area can be found in the key or legend of a map OR you can view online resources (like NOAA) to find a declination of a specific area. Setting your declination will vary from compass to compass.
The goal is to adjust the Orienting Arrow to the declination degree of the area.
In both of these illustrations of compasses, the Bezel (or black ring on with the degree markings) does not move, only adjusting the Orienting Arrow.
The Compass on the far right is now properly adjusted to the declination of Acadia National Park.
Once you've adjusted declination for your area, you can just focus on navigating.
Want to know more basic compass information?
Check out our clinics with the links below, and make sure to check back as we are adding content.
This article was originally published by Brunton. Republished with permission.
